Black Graphite Coated High Temperature Fiberglass Cloth with 750℃ Temperature Resistance and Abrasion Resistant Properties

  • Black Graphite Coated High Temperature Fiberglass Cloth with 750℃ Temperature Resistance and Abrasion Resistant Properties
  • Black Graphite Coated High Temperature Fiberglass Cloth with 750℃ Temperature Resistance and Abrasion Resistant Properties
  • Black Graphite Coated High Temperature Fiberglass Cloth with 750℃ Temperature Resistance and Abrasion Resistant Properties
  • Black Graphite Coated High Temperature Fiberglass Cloth with 750℃ Temperature Resistance and Abrasion Resistant Properties
  • Black Graphite Coated High Temperature Fiberglass Cloth with 750℃ Temperature Resistance and Abrasion Resistant Properties
  • Black Graphite Coated High Temperature Fiberglass Cloth with 750℃ Temperature Resistance and Abrasion Resistant Properties
  • Black Graphite Coated High Temperature Fiberglass Cloth with 750℃ Temperature Resistance and Abrasion Resistant Properties
  • Black Graphite Coated High Temperature Fiberglass Cloth with 750℃ Temperature Resistance and Abrasion Resistant Properties
  • Black Graphite Coated High Temperature Fiberglass Cloth with 750℃ Temperature Resistance and Abrasion Resistant Properties
Место происхождения Китай
Фирменное наименование SUNTEX
Номер модели TGF880-GP235-5001
Количество мин заказа 20 роллов
Упаковывая детали Каждый рулон в картонной упаковке, несколько коробок на поддоне.
Время доставки 5-20 дней
Условия оплаты Т/Т; Л/К, ПайПал...
Поставка способности 500000кв.м/месяц
Подробная информация о продукте
Вес единицы ткань стеклоткани 28.82oz/sqy Стандартная ширина 1000mm 1520mm 2000mm
Стандартная толщина 0,039 дюйма Цвет Черный
Картина ткани стеклоткани Простой Температурная стойкость покрытия 750℃ 1300℉
Базовая термостойкость ткани 550℃ 1000℉ Покрытие Стороны графита 2
Выделить

black graphite coated fiberglass cloth

,

high temperature fire resistant fabric

,

industrial abrasion resistant fiberglass cloth
Оставьте сообщение
Характер продукции

Fireproof Blanket High Temperature Fiberglass Fabric 29OZ Graphite Coated Fire Protection Fabric



Introduce



TGF880-GP235-5001 is a medium weight woven texturized fiberglass fabric coated with a specially formulated graphite and polyurethane solution which provides high temperature and abrasion resistance properties for the manufacturer of gaskets, flexible expansion joints, removable jackets and other types of fire control systems.



Fiberglass Cloth​ Advantage



1. Well certified fire resistance.

2. Black color.

3. Easy to be applied, sewn and fabricated.

4. Well abrasion resistance property.

5. Well tensile strength.

6. Nominal thickness, unit weight, pattern, all can be customized base on your use method.



Data



Standard weight 28.82 oz/y2
Standard Thickness 0.039 inch
Standard width 1000mm 1550mm 2000mm
Coating Graphite
Colour Black
Fire resistance Well
Coating temperature resistance Graphite coating 750 ℃
Basic fabric working temperature Basic fabric 550 ℃
Pattern Plain
Yarn warp ETG 8.6
Yarn weft ETG 8.6
Construction warp 25 ± 2 ends/inch
Construction weft 20 ± 1 ends/inch
Fiberglass E-Glass Texturized Woven Fabric



Applications



Fire curtain/door

Welding blanket

Compensator

Removable heat insulation couples

Heat insulation Mattress

Fabric duct



Related Products



Style No. Weight Thickness Color Coating
g/m2 oz/yd2 mm inch
TGF880-GP235-5001 980 28.8 1.0 0.039 Black 2 sides
TGF1000-GP235-5002 1100 32.4 1.4 0.055 Black 2 sides
TGF1250-GP235-5003 1400 41.2 1.6 0.063 Black 2 sides
TGF2050-GP245-5004 2250 66 2.5 0.098 Black 2 sides
TGF1000S-GP235-5015 1180 35 1.5 0.059 Black 2 sides
TGF2550-GP225-5020 2650 78 2.6 0.102 Black 2 sides
